Dreco Cantilever Triple 1500 HP Rig 24
DrecoModel:P1604008
Houston, TX
Oilfield Drilling Equipment
Qty:1
Condition: Used
At a glance
- Product
- Dreco Cantilever Triple 1500 HP Rig 24
- Manufacturer
- Dreco
- Model
- P1604008
- Category
- Oilfield Drilling Equipment
- Condition
- USED
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Houston, TX
- Fulfillment
- Pickup and shipping available
- Listed on
Key specifications
- Drawworks & Top Drive Block
- Dreco 642TB375, 375-ton
- Drawworks & Top Drive Brake
- Dynamic Disc Brake
- Drawworks & Top Drive Continuous Torque
- 32,500 ft-lbs
- Drawworks & Top Drive Drawworks MFG
- NOV DSGD 375
- Drawworks & Top Drive Drive
- NOV CM632UUT
- Drawworks & Top Drive Make-Up Torque
- 47,000 ft-lbs
- Drawworks & Top Drive Power
- 1,500 HP / 1,100 kW
- Drawworks & Top Drive Top Drive
- Varco TDS 11SA
- Drawworks Brake
- Dynamic Disc Brake
- Drawworks Drive
- NOV CM632UUT
- Drawworks MFG / Model
- NOV DSGD 375
- Drawworks Power
- 1,500 HP / 1,100 kW
- Drawworks Single Line Pull
- 84,184 lbs
- Drill Line Diameter
- 1.25in
- Mast & Structure Lines
- 12 lines, 1¼" drill line
- Mast & Structure Mast
- Dreco Model P1604008 Cantilever Triple
- Mast & Structure Mast Height
- 142 ft clear
- Mast & Structure Rotary Table
- 37.5" / 952 mm, 350-ton
- Mast & Structure Static Hook Load
- 750,000 lbs / 333,617 daN
- Mast & Structure Substructure
- One-Piece Telescoping (Dreco de156358)
- Mast 8-Line Capacity
- 750,000 lbs / 333,617 daN
- Mast Clear Height
- 142 ft
- Mast Drill Line
- 1¼" / 31.7 mm
- Mast Lines
- 12
- Mast MFG / Model
- Dreco P1604008
- Mast Static Hook Load
- 750,000 lbs / 333,617 daN
- Mast Type
- Cantilever Triple
- Mud Pump Power per Unit
- 1600HP
- Mud Pump Pressure Rating
- 7500psi
- Mud Pumps Drive
- Baylor Induction Motor (x2)
- Mud Pumps Gear Box MFG
- Gardner Denver
- Mud Pumps Gear Box Ratio
- 7.842:1
- Mud Pumps Model
- Gardner Denver Maverick (x2)
- Mud Pumps Power per Pump
- 1,500 HP / 1,192 kW
- Mud Pumps Stroke Length
- 11"
- Mud Pumps System Pressure
- 7,500 PSI
- Mud System Gear Box
- Gardner Denver 7.842:1
- Mud System Mud Pumps
- (2) Gardner Denver Maverick, 1,500 HP each
- Mud System Pump Drive
- (2) Baylor Induction Motors
- Mud System Stroke Length
- 11"
- Mud System System Pressure
- 7,500 PSI
- Number of Drilling Lines
- 12
- Rotary Table Capacity
- 350ton
- Rotary Table Size
- 37.5in
- Static Hook Load
- 750000lb
- Substructure Casing Capacity
- 750,000 lbs / 333,617 daN
- Substructure Floor Height
- 20'-0" / 6.09 m
- Substructure MFG
- Dreco de156358
- Substructure Racking Capacity
- (4.0") 5,500 m â SS-105 CDS40
- Substructure Rotary Capacity
- 350 ton
- Substructure Rotary Table
- 37.5" / 952 mm
- Substructure Setback Capacity
- 460,000 lbs / 204,618 daN
- Substructure Type
- One-Piece Telescoping
- Substructure Under Table Height
- 17'-6" / 5.36 m
- Top Drive & Block Block
- Dreco 642TB375, 375 ton / 341,000 daN
- Top Drive & Block Break-Out Torque
- 56,000 ft-lbs / 24,900 Nm
- Top Drive & Block Continuous Torque
- 32,500 ft-lbs / 14,450 Nm
- Top Drive & Block Make-Up Torque
- 47,000 ft-lbs / 20,900 Nm
- Top Drive & Block Top Drive
- Varco TDS 11SA
- Top Drive Makeup Torque
- 47000ft-lb
- Traveling Block Capacity
- 375ton
Supporting evidence
No supporting documents or certifications provided.
Description
Dreco P1604008 Cantilever Triple 1500 HP land rig rated to 5,000 m (16,400 ft) TMD. Features NOV DSGD 375 drawworks (1,500 HP / 1,100 kW), Dreco 642TB375 500-ton traveling block, Varco TDS 11SA top drive with 47,000 ft-lb make-up torque, dual Gardner Denver Maverick mud pumps at 7,500 PSI, and one-piece telescoping substructure with 37.5" rotary table.
