Cardwell 375 HP Workover Rig 320
CardwellModel:KB-200-C
Houston, TX
Well Servicing Equipment
Qty:1
Condition: Used
At a glance
- Product
- Cardwell 375 HP Workover Rig 320
- Manufacturer
- Cardwell
- Model
- KB-200-C
- Category
- Well Servicing Equipment
- Condition
- USED
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Houston, TX
- Fulfillment
- Pickup and shipping available
- Listed on
Key specifications
- Choke Manifold Adjustable Choke
- 1" passage
- Choke Manifold Size/Working Pressure
- 2-9/16" â 5,000 PSI (skid-mounted)
- Discharge Pressure
- 219PSIG
- Drawworks Bails
- 1-3/4" Ã 72" â 150 TN
- Drawworks Drilling Line
- 1" â 46 TN API 9th Standard
- Drawworks Engine
- Scania DC-9
- Drawworks Horsepower
- 375HP
- Drawworks Input Power
- 375 HP
- Drawworks Make
- Cardwell KB-200-C
- Drawworks Make/Model
- Cardwell KB-200-C
- Drawworks Model
- Cardwell KB-200-C
- Drawworks Pulling Capacity
- 95 TN
- Drawworks Swabbing Line
- 9/16" â Reel 3,600 m
- Drawworks Transmission
- Allison OFS 4700
- Drawworks Tubing Floor Capacity
- 3,042 m
- Injection Circuit / Pit System Atmospheric Hammer
- Vertical
- Injection Circuit / Pit System Choke Manifold
- 2" â 3,000 PSI
- Injection Circuit / Pit System Pits
- 4
- Injection Circuit / Pit System Test Pit Capacity
- 33 m³ (2 control pits 5 m³ each, 1 low-flow pit 0.2 m³)
- Manifold Pressure
- 5000in. WC
- Mast Crown Block
- Cardwell, 6 Lines
- Mast Height
- 96 FT
- Mast Make
- Cardwell
- Mast Nominal Capacity
- 180,000 LBS
- Mast Type
- Rectangular / Telescopic
- Mast VTA
- Equipped
- Maximum Output
- 1096GPD
- Mud Pump Engine
- Scania DC-9, 330 HP
- Mud Pump Make/Model
- Gardner Denver PAHAJ
- Mud Pump Max Flow Rate
- 1,096 LPM @ 97 Kg/cm²
- Mud Pump Max HHP
- 275 HHP / 0.285 m³/min
- Mud Pump Max Pressure
- 219 Kg/cm²
- Mud Pump Model
- Gardner Denver PAHAJ
- Mud Pump Power per Unit
- 275HP
- Mud Pump Quantity
- 1
- Mud Pump Stroke
- 8-4½" à 8" â 6.2 LPE
- Mud System Auxiliary Pit
- 39 m³ (two compartments: 26 + 13 m³)
- Mud System Auxiliary Pit 2
- 39 m³ (26 m³ + 13 m³)
- Mud System Capacity
- 111BBLS
- Mud System Remote Test Pit
- 33 m³
- Mud System Swabbing Line
- 9/16" â 3,600 m Reel
- Mud System Total Volume
- 111 m³
- Mud System Tubing
- 2-7/8" â 4,500 m capacity
- Mud System Tubing Floor Capacity
- 3,042 m
- Mud System Tubing Load Capacity
- 2-7/8" tubing â 4,500 m @ 2.94 kg/m
- Pulldown Capacity
- 95lb
- Rotary Table Make
- Ideco
- Rotary Table Model
- SR 17.5
- Rotary Table Opening
- API 17½"
- Rotary Table Size
- 17.5in
- Rotary Table VTA
- Equipped
- Static Hook Load
- 180000lb
- Substructure Floor Height
- 3.2 m
- Substructure Height
- 3.2ft
- Substructure Max Capacity
- 160 TN
- Trip Curve
- 4
- Trip Tank Capacity
- 4 m³
- Trip Tank Level Indicator
- YES
- Tubing Capacity
- 4500m
- Well Control Adjustable Choke
- 1" passage
- Well Control Choke Manifold
- 2-9/16" 5,000 PSI (skid-mounted)
- Well Control Trip Tank
- 4 m³ with Level Indicator
Supporting evidence
No supporting documents or certifications provided.
Description
Versatile 375 HP Cardwell KB-200-C workover rig (Unit 320) configured for tubing pull, swabbing, and recompletion operations. Features a 96-ft rectangular telescopic mast rated at 180,000 lbs, a Gardner Denver PAHAJ mud pump delivering 275 HHP at up to 219 Kg/cm² pressure, and a 111 m³ multi-compartment mud system. Carrier-mounted with VTA on all key components.
