Brewster N4-A 750HP Drilling Rig 1
BrewsterModel:N4-A
Houston, TX
Oilfield Drilling Equipment
Qty:1
Condition: Used
At a glance
- Product
- Brewster N4-A 750HP Drilling Rig 1
- Manufacturer
- Brewster
- Model
- N4-A
- Category
- Oilfield Drilling Equipment
- Condition
- USED
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Houston, TX
- Fulfillment
- Pickup and shipping available
- Listed on
Key specifications
- Ancillary Equipment Crown Block
- Superior, 5 Ã 36" Sheaves
- Ancillary Equipment Drill Water Tank
- 513 bbl
- Ancillary Equipment Fuel Tank
- 8,000 Gallon w/ Lubester
- Ancillary Equipment Mud Tanks
- 2-tank, 560 bbl Round Bottom
- Ancillary Equipment Rotary
- 17-1/2" Ã 44-1/4" RT-175
- Ancillary Equipment Swivel
- Emsco LB200, 200-Ton
- Ancillary Equipment Traveling Block
- 160-Ton Ideco UTB, 4 Sheaves
- Ancillary Equipment Wireline Unit
- Mathey GC-B2, .092 Line
- BOP & Well Control Accumulator
- CAD Type M, 3,000 psi, 10-gal bottles
- BOP & Well Control Annular
- GK Hydrill 11" 900 Series, 3,000 psi
- BOP & Well Control Choke Manifold
- 5,000 psi, 4" Ã 2"
- BOP & Well Control Double Ram
- NL Shaffer 11" LWS 3,000 psi
- BOP Annular
- GK Hydrill 11" 900 Series, 3,000 psi
- BOP Choke Manifold
- 5,000 psi, 4" Ã 2", Two Adj. Chokes
- BOP Double Ram
- NL Shaffer 11" LWS, 3,000 psi
- Brake System Type
- Parmac SR 22 Single Hydromatic
- Certification Year
- 2024
- Compound Type
- Two Engine Split Oil Bath
- Derrick Height
- 105ft
- Derrick Hook Load
- 300,000 lbs (8 lines)
- Derrick Make/Height
- Superior, 105 ft
- Derrick RKB Height
- 13'5"
- Derrick Rotary Beam Clearance
- 9'4" to Bottom Sub
- Derrick Substructure
- Lee C. Moore Triaxle Trailer
- Drawworks & Rotary Brake
- Parmac SR 22 Hydromatic
- Drawworks & Rotary Drawworks
- Brewster Model N4-A
- Drawworks & Rotary Drill Line
- 1-1/8" grooved
- Drawworks & Rotary Pipe Spinner
- Varco SS10
- Drawworks & Rotary Rotary
- 17-1/2" Ã 44-1/4" RT-175
- Drawworks Brake
- Parmac SR 22 Single Hydromatic
- Drawworks Drill Line
- 1-1/8" grooved
- Drawworks Model
- Brewster N4-A
- Drill Line Diameter
- 1-1/8 inchin
- Drill String Drill Collars
- 6"â6-1/4" OD Slick NC44 w/Hardband
- Drill String Drill Pipe
- 4" OD 14.40# Grade G-105, Full Hole w/Hardband
- Drill String Kelly
- Omsco 5-1/4" Ã 36' HP
- Engine Horsepower
- 830HP
- Engine Model
- Caterpillar C-13
- Engine Quantity
- 2
- Mast & Substructure Derrick
- Superior, 105 ft
- Mast & Substructure Hook Load
- 300,000 lbs (8 lines)
- Mast & Substructure RKB Height
- 13'5"
- Mast & Substructure Rotary Clearance
- 9'4" to Bottom Sub
- Mast & Substructure Trailer
- Lee C. Moore Triaxle
- Max Static Hook Load
- 275000lb
- Mud Pumps Power
- Cat C32 w/ National C-245-64 TC each
- Mud Pumps Type
- 2 Ã Emsco F-1000, 6-3/4" Ã 10" Triplex
- Mud System Desander
- Derrick (2) 12" cones
- Mud System Desilter
- Derrick (12) 4" cones
- Mud System Mud Tanks
- 2-tank, 560 bbl round bottom
- Mud System Pump Power
- Cat C32 with National C-245-64 TC
- Mud System Pumps
- 2 Ã Emsco F-1000, 6-3/4" Ã 10" Triplex
- Mud System Shakers
- 2 Ã Brandt Alpha Linear Motion
- Power Air Compressors
- 2 Ã Sullivan 300-DG-TE
- Power Engines
- 2 Ã Caterpillar C-13 Diesel, 830 HP total
- Power Generators
- 2 Ã 410KW, Cat C-15 Tier 4 @ 626 HP each
- Power System Air Compressors
- 2 Ã Sullivan 300-DG-TE Screw Type
- Power System Engines
- 2 Ã Cat C-13 Diesel, 830 HP total
- Power System Generators
- 2 Ã 410KW (2 Ã Cat C-15 Tier 4, 626 HP)
- Power System Torque Converters
- Twin Disc F-11524-TCIL
- Power Torque Converters
- Twin Disc F-11524-TCIL
- Pricing Certified
- 2024
- Pricing Maintenance
- Critical components covered by Lessor
- Pricing Pricing
- Contact for Pricing
- Pricing Program
- Lease-to-Own
- Rated Power
- 750kW
- Rotary Beam Clearance
- 10.75ft
- Rotary Kelly Bushing (RKB) Height
- 13ft
- Torque Converters
- Twin Disc F-11524-TCIL
- Trailer Base
- Lee C. Moore Triaxle
Supporting evidence
No supporting documents or certifications provided.
Description
Brewster N4-A 750HP mechanical drilling rig, certified in 2024 and available on a lease-to-own basis. Critical components covered by the lessor. Features a 105 ft Superior Derrick with 300,000 lb hook load, two Caterpillar C-13 engines (830 HP total), dual Emsco F-1000 triplex mud pumps, and a full solids-control system. Drill pipe and BOP included.
