ZJ30 750HP Truck-Mounted Workover Rig - Iraq
UnknownModel:ZJ30
Houston, TX
Well Servicing Equipment
Qty:1
Condition: Used
At a glance
- Product
- ZJ30 750HP Truck-Mounted Workover Rig - Iraq
- Manufacturer
- Not provided
- Model
- ZJ30
- Category
- Well Servicing Equipment
- Condition
- USED
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Houston, TX
- Fulfillment
- Pickup and shipping available
- Listed on
Key specifications
- Ambient Temperature Limits Max
- +55°C°F
- Ambient Temperature Limits Min
- -20°C°F
- Drawworks Brake Cooling
- Water cooled
- Drawworks Brake System
- Mechanical + Auxiliary
- Drawworks Power
- 750HP
- Drawworks Rated Power
- 750 HP (550 kW)
- Drawworks Sand Drum
- Included
- Drill Floor Size Width
- 6m
- Drill Line Diameter
- Φ32 mm / 1.25"in
- Drilling Depth Capacity (5")
- 3000ft
- Electrical System Generator Set
- Diesel generator house
- Electrical System Lighting System
- Included
- Electrical System Well-site Circuit
- Parallel control cabinet
- Engine & Drawworks Drawworks Rated Power
- 750 HP (550 kW)
- Engine & Drawworks Engine Model
- Caterpillar C15
- Engine & Drawworks Rotary Table Drive
- Via drawworks compound transfer box
- Engine Configuration
- Truck-mounted drive train
- Engine Generator Set
- Diesel generator house included
- Engine Model
- Caterpillar C15
- Engine Rated Power
- 750HP
- Engine Rig Rated Power
- 750 HP (550 kW)
- General Specifications Clear Height of Substructure
- 4.9 m
- General Specifications Drilling Depth
- 3,000 m (4.5" DP)
- General Specifications Drilling Floor Height
- 6 m
- General Specifications Drilling Line Diameter
- Φ32 mm / 1.25"
- General Specifications Lines
- 5Ã6
- General Specifications Location
- Iraq
- General Specifications Mast Height
- 38 m
- General Specifications Max Static Load
- 1,800 kN
- General Specifications Model
- ZJ30
- General Specifications Temperature Range
- -20°C to +55°C
- Mast Drilling Floor Height
- 6 m
- Mast Height
- 38 m
- Mast Lines
- 5Ã6
- Mast Max Hook Load
- 1,800 kN
- Mast Max Static Load
- 1,800 kN
- Mast Racking Board Heights
- 22 / 23 / 24 m
- Mast Type
- Two-section Telescoping, Front-open, Hydraulic Raise
- Max Static Hook Load
- 1800lb
- Mud Pumps
- Triplex
- Mud System Agitators
- 5.5 kW and 15 kW units
- Mud System Desander / Desilter
- Included
- Mud System Mixing System
- Mixing hoppers and pumps
- Mud System Mud Degasser
- Included
- Mud System Mud Pump
- Triplex (dedicated pump unit)
- Mud System Pill Tank
- Included
- Mud System Pump Engine
- Diesel
- Mud System Reserve Tank
- Shearing pump
- Mud System Settling Tank
- Desander + desilter
- Mud System Shaker Tank
- Shale shaker + degasser + trip pump
- Mud System Shale Shakers
- Included
- Mud System Suction Tank
- Mixing pump + mixing hopper
- Mud System Tanks
- Shaker, Settling, Suction, Reserve, Pill, Water tanks
- Mud System Water Tanks
- Included
- Transport & Carrier Configuration
- Truck-mounted, self-propelled
- Transport & Carrier Hydraulic Jacks
- Levelling jacks included
- Transport & Carrier Mast Raising
- Hydraulic cylinder system
- Transport & Carrier Temperature Range
- -20°C to +55°C
- Well Control BOP Annular
- Included
- Well Control BOP Control System
- Hydraulic accumulator
- Well Control Choke Manifold
- With remote console
- Well Control Double Ram BOP
- Included
- Well Control Drilling Spool
- Included
- Well Control HCR Valve
- Hydraulic flat gate valve
- Well Control IBOP
- Included
- Well Control Kill Manifold
- Included
Supporting evidence
No supporting documents or certifications provided.
Description
A 750 HP (550 kW) ZJ30 series truck-mounted drilling and workover land rig currently located in Iraq. Powered by a Caterpillar C15 engine, the rig is rated to 3,000 metres on 4.5-inch drill pipe with a maximum static hook load of 1,800 kN. Features a two-section telescoping mast at 38 metres, full BOP stack, mud circulation system with shale shakers and degasser, AC electrical system, and complete auxiliary packages. All-in-one transport design suits remote locations and fast mobilisation.
