Neway 10-Inch Class 150 Cast Duplex Stainless Steel Gate Valve Fig. No. 10G1RZF53HFW-T-600-NC-G
Neway Valve (Suzhou) Co., Ltd.Model:10G1RZF53HFW-T-600-NC-G
Red Deer, AB
Gate Valve
Qty:1
Condition: New
At a glance
- Product
- Neway 10-Inch Class 150 Cast Duplex Stainless Steel Gate Valve Fig. No. 10G1RZF53HFW-T-600-NC-G
- Manufacturer
- Neway Valve (Suzhou) Co., Ltd.
- Model
- 10G1RZF53HFW-T-600-NC-G
- Category
- Gate Valve
- Condition
- NEW
- Availability
- In stock
- Price or process
- Make an offer
- Quantity
- 1
- Lead time
- Not provided
- Location
- Red Deer, AB
- Fulfillment
- Pickup and shipping available
- Seller
- OTG
- Listed on
Key specifications
- Body Material
- ASTM A995 Grade 6A (Duplex Stainless Steel)
- Compliance Standards
- :[
- Disc Material
- HF (Hard Faced)
- End Connection
- Raised Face Flanged (RF) per ASME B16.5
- Maximum Operating Pressure (WOG at 100°F)
- 290psi
- Maximum Operating Pressure (WOG at 400°F)
- 200psi
- Nominal Pipe Size
- 10in
- Operator Type
- Handwheel (Manual)
- Pressure Class
- 150
- Seat Material
- F53 (Super Duplex Stainless Steel)
- Stem Material
- F53 (Super Duplex Stainless Steel)
Supporting evidence
No supporting documents or certifications provided.
Description
The Neway 10-Inch Class 150 Gate Valve, model Fig. No. 10G1RZF53HFW-T-600-NC-G, is a robust, flanged gate valve designed for reliable shut-off in industrial piping systems. Constructed from ASTM A995 Grade 6A duplex stainless steel body with F53 super duplex stainless steel seat and stem, and a hard-faced disc, it offers excellent corrosion resistance and durability in harsh environments, including those requiring NACE MR0175 compliance for sour service. This valve is suitable for applications in oil and gas, petrochemical, and water treatment industries, handling water, oil, and gas (WOG) up to 290 psi at 100°F and 200 psi at 400°F. Key features include a bolted bonnet, rising stem, and handwheel operator for manual operation. Advantages over similar products include superior material strength for high-pressure and corrosive media, reduced maintenance due to durable components, and compliance with API 600 and ASME B16.34 standards. Drawbacks may include higher initial cost due to premium materials and potential weight impacting installation.
