DSI Globe Valve Fig. 66LUF-N – 2" Class 600 WCB/Stainless Trim 12
DSI ValvesModel:66LUF-N
Red Deer, AB
Globe Valve
Qty:1
Condition: New
At a glance
- Product
- DSI Globe Valve Fig. 66LUF-N – 2" Class 600 WCB/Stainless Trim 12
- Manufacturer
- DSI Valves
- Model
- 66LUF-N
- Category
- Globe Valve
- Condition
- NEW
- Availability
- In stock
- Price or process
- Make an offer
- Quantity
- 1
- Lead time
- Not provided
- Location
- Red Deer, AB
- Fulfillment
- Pickup and shipping available
- Seller
- OTG
- Listed on
Key specifications
- API Trim Number
- Trim 12
- Body Material
- A216 WCB (Carbon Steel)
- Bonnet Type
- Bolted Bonnet (Pressure Seal Gasket)
- CE Mark
- true
- Cold Working Pressure
- 1480psi
- Connection Type
- ASME B16.5 RF, 2 " Class 600
- Design Standard
- API 600 / ASME B16.34
- Disc Material
- 316 Stainless Steel
- Face-to-Face Length
- 14in
- Max Temperature
- 800°F
- Nominal Pipe Size
- 2in
- Operation
- Manual handwheel
- Pressure Class
- Class 600
- Seat Material
- Hard-faced (Stellite®)
- SKU
- V-379
- Stem Material
- 316 Stainless Steel
- Testing Standard
- API 598
Supporting evidence
No supporting documents or certifications provided.
Description
The DSI Fig. 66LUF-N is a bolted-bonnet, rising-stem globe valve designed for positive shut-off and throttling service in high-pressure process and pipeline applications. Sized at 2 in. and built to ASME Class 600 (1 480 psi @ 100 °F), this unit features a carbon-steel WCB body for broad chemical compatibility and a hard-faced (HF/Stellite) seat with 316 SS disc and stem (API Trim 12) to resist galling and erosion at elevated temperatures to 800 °F. Flanged RF ends to ASME B16.5 simplify installation, while the inside screw/yoke and handwheel provide reliable manual operation. Compared with commodity gate valves, the globe pattern delivers finer flow control and faster closing times, making it ideal for blow-down, control bypass, and isolation of steam, hydrocarbon, or utility lines. API 600 design, API 598 test and CE marking assure global code compliance. This unit appears to be unused surplus with flange protectors intact; exterior rust/paint loss on the handwheel reflects yard storage only.
