2016 Sixth Generation Ultra-Deepwater Semisubmersible
Moss Maritime (design)Model:CS60E
Houston, TX
Oilfield Drilling Equipment
Qty:1
Condition: Used
At a glance
- Product
- 2016 Sixth Generation Ultra-Deepwater Semisubmersible
- Manufacturer
- Moss Maritime (design)
- Model
- CS60E
- Category
- Oilfield Drilling Equipment
- Condition
- USED
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Houston, TX
- Fulfillment
- Pickup and shipping available
- Listed on
Key specifications
- Accommodation Capacity
- 180
- BOP Rating
- 18-3/4" 15,000 psi (2A/6R)
- Classification
- DnV +A1, DYNPOS-AUTRO, BIS, E0
- Derrick & Hoisting Base
- 50 ft à 52 ft
- Derrick & Hoisting Compensator
- NOV CMC-H-1000-25, 500 ST @ 25 ft stroke
- Derrick & Hoisting Derrick
- NOV SDBN Bottleneck, 210 ft high
- Derrick & Hoisting Drawworks
- NOV SSGD â 5,750 HP
- Derrick & Hoisting Hook Load
- 1,000 ST
- Derrick & Hoisting Top Drive
- NOV TDX-1000, 1,000 ST, 2,000 HP
- Displacement
- 68375cc
- DP & Station Keeping Chain
- 84mm NV R5 â Stevpris Mk6 18MT anchors
- DP & Station Keeping Cranes
- 2x Seatrax S-108, 100 MT @ 42 ft
- DP & Station Keeping DP System
- Kongsberg K-POS, K-Chief, K-Safe
- DP & Station Keeping Mooring
- 8x Rolls-Royce winches, 450 MT rated
- DP & Station Keeping Thrusters
- 8x Thrustmaster 4,800 kW azimuth
- DP & Station Keeping Transit Speed
- Up to 10 knots
- Drawworks Power
- 5750HP
- Drilling Depth Capacity
- 35000ft
- Drilling Equipment Derrick
- NOV SDBN Bottleneck, 210 ft, 1,000 ST
- Drilling Equipment Drawworks
- NOV SSGD, 5,750 HP
- Drilling Equipment Mud Pumps
- 4x NOV 14-P-220, 2,200 HP, 7,500 psi
- Drilling Equipment Rotary Table
- NOV RST 60-1/2" hydraulic, 1,134 MT
- Drilling Equipment Shale Shakers
- 6x NOV VSM Multisizers
- Drilling Equipment Top Drive
- NOV TDX-1000, 1,000 ST, 2,000 HP
- General Accommodation
- 180 persons
- General Classification
- DnV +A1, DYNPOS-AUTRO, BIS, E0
- General Design
- Moss CS60E
- General Displacement
- 68,375 MT
- General Draft (Drilling)
- 77 ft
- General Drilling Depth
- 35,000 ft
- General Main Deck
- 315 ft à 255 ft
- General Variable Deck Load
- 7,500 MT drilling
- General Water Depth
- 9,840 ft (3,000 m) outfitted
- General Year Entered Service
- 2016
- Hook Load Capacity
- 1000ST
- Maximum Water Depth
- 9840ft
- Mud Pump Rating
- [object Object]
- Mud System Drill Water
- 12,674 bbl
- Mud System Fuel
- 28,411 bbl
- Mud System Liquid Mud
- 15,051 bbl (triple-pit segregated)
- Mud System Mud Pumps
- 4x NOV 14-P-220
- Mud System Pump Rating
- 2,200 HP, 7,500 psi each
- Mud System Shale Shakers
- 6x NOV VSM Multisizers
- Power & DP DP
- Kongsberg K-POS
- Power & DP Main Power
- 8x Himsen diesel, 6,120 kW each
- Power & DP Thrusters
- 8x Thrustmaster 4,800 kW azimuth
- Power & DP Total Power
- 48,960 kW
- Storage Bulk Cement
- 15,891 ft³
- Storage Drill Water
- 12,674 bbl
- Storage Fuel
- 28,411 bbl
- Storage Liquid Mud
- 15,051 bbl (triple-pit)
- Storage Potable Water
- 5,516 bbl
- Subsea & BOP BOP
- NOV Class 8, 18-3/4" 15,000 psi (2A/6R)
- Subsea & BOP C&K Manifold
- 3-1/16" 15,000 psi
- Subsea & BOP Marine Riser
- NOV FT-H 21", 75 ft/joint
- Subsea & BOP Moonpool
- 95 ft à 29.5 ft
- Subsea & BOP Tensioners
- 16x 225-kip NOV, 3,600 kips total
- Subsea & BOP XT Carts
- 4x 100 MT
- Subsea BOP
- NOV Class 8 18-3/4" 15,000 psi (2A/6R)
- Subsea Marine Riser
- NOV FT-H 21", 75 ft/joint
- Subsea Moonpool
- 95 ft à 29.5 ft
- Subsea Tensioners
- 16x 225-kip, 3,600 kips total
- Thruster Power
- 4800kW
- Top Drive Capacity
- [object Object]tons
- Total Power Generation
- 48960kW
- Variable Deck Load
- 7500t
Supporting evidence
No supporting documents or certifications provided.
Description
A sixth-generation ultra-deepwater semisubmersible on the Moss CS60E design, delivered in 2016. Rated to 9,840 ft water depth with DP and mooring capability, the rig features a 5,750 HP NOV SSGD drawworks, NOV TDX-1000 1,000-ton top drive, four 2,200 HP mud pumps at 7,500 psi, and eight 4,800 kW Thrustmaster azimuth thrusters. DnV classified with 180-person accommodation and a triple-pit segregated mud system for simultaneous handling of WBM, NAF, and brine.
