Instrument Transformers LPVR-480 Phase Voltage Relay Monitor 360-500V 3PH 60Hz
Instrument Transformers Inc.Model:LPVR-480
Location unavailable
Relays
Qty:1
Condition: New
At a glance
- Product
- Instrument Transformers LPVR-480 Phase Voltage Relay Monitor 360-500V 3PH 60Hz
- Manufacturer
- Instrument Transformers Inc.
- Model
- LPVR-480
- Category
- Relays
- Condition
- NEW
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Location unavailable
- Fulfillment
- Shipping only
- Seller
- Motor Control Center
- Listed on
Key specifications
- Control Voltage
- 24,120,208,240,380,480,575
- Enclosure Rating
- NEMA 1 (estimated based on design; confirm with datasheet)
- Frequency
- 60Hz
- Output Type
- SPDT (Single Pole Double Throw)
- Phase Configuration
- 3 Phase
- Temperature Max
- 60°F
- Temperature Min
- -20°F
- Unbalance Trip
- 10%%
- Voltage Max
- 500V
- Voltage Min
- 360V
Supporting evidence
No supporting documents or certifications provided.
Description
The Instrument Transformers LPVR-480 is a compact phase voltage relay monitor designed for three-phase electrical systems, providing reliable protection against voltage imbalances, overvoltage, undervoltage, and phase loss. This device is ideal for industrial applications such as motor protection, power distribution panels, and critical machinery in manufacturing, utilities, and commercial facilities. It features adjustable settings for system unbalance (up to 10% trip), delay times, and voltage thresholds, allowing customization to specific operational needs. Key benefits include enhanced equipment longevity by preventing damage from voltage anomalies, quick fault detection with LED indicators, and easy integration via plug-in design. Compared to similar products like those from Basler or SEL, the LPVR-480 offers superior adjustability and a robust build for harsh environments, though it may require manual calibration, which could be a drawback for automated systems. Its UL-listed construction ensures safety compliance, and it operates efficiently in 60Hz systems with a voltage range of 360-500V. Overall, this relay monitor excels in providing cost-effective, real-time monitoring to minimize downtime and maintenance costs in high-stakes electrical setups.
