Allen-Bradley MPL-B320P-MK74AA Kinetix MP-Series Low-Inertia Servo Motor
Allen-BradleyModel:MPL-B320P-MK74AA
Location unavailable
Motors
Qty:1
Condition: New
At a glance
- Product
- Allen-Bradley MPL-B320P-MK74AA Kinetix MP-Series Low-Inertia Servo Motor
- Manufacturer
- Allen-Bradley
- Model
- MPL-B320P-MK74AA
- Category
- Motors
- Condition
- NEW
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Location unavailable
- Fulfillment
- Shipping only
- Seller
- Controlview Automation
- Listed on
Key specifications
- Ambient Temperature Max
- 40°F
- Ambient Temperature Min
- 0°F
- Brake Option
- true
- Brake Voltage
- 24 V DCV DC
- Continuous Stall Torque
- 3.05Nm
- Feedback Type
- Multi-turn high-resolution absolute encoder (1024 sin/cos)
- Frame Size
- 100
- Insulation Class
- Class H (180°C)
- IP Rating
- IP66 (with shaft seal)
- Peak Torque
- 7.9in-lbs
- Power Rating
- 1.5W
- Rated Speed
- 5000RPM
- Rated Voltage
- 460 V RMS L-L 3-PhaseVDC
Supporting evidence
No supporting documents or certifications provided.
Description
The Allen-Bradley MPL-B320P-MK74AA is a high-performance servo motor from the Kinetix MP-Series, designed for low-inertia applications requiring precise control and rapid acceleration. This 460V AC motor delivers 1.5 kW (2 HP) continuous power at 5000 RPM, with continuous stall torque of 3.05 Nm (27 lb-in) and peak torque up to 7.9 Nm (70 lb-in). It features a multi-turn high-resolution absolute encoder for accurate positioning, a 24V DC holding brake for safety and load retention, and SpeedTec DIN connectors for quick installation. Ideal for automation in packaging, material handling, and robotics, it offers advantages like compact design, high torque density, and seamless integration with Allen-Bradley Kinetix drives. Benefits include energy efficiency and reduced downtime due to robust construction, while drawbacks may include higher cost compared to standard motors and the need for compatible drive systems. Compared to similar products like Siemens or Fanuc servos, it excels in Rockwell ecosystem compatibility and dynamic response. The unit appears used with minor cosmetic wear but functional integrity based on visual inspection.
