2009 Fifth Generation Ultra-Deepwater Semisubmersible
Odeco (design)Model:Victory
Houston, TX
Oilfield Drilling Equipment
Qty:1
Condition: Used
At a glance
- Product
- 2009 Fifth Generation Ultra-Deepwater Semisubmersible
- Manufacturer
- Odeco (design)
- Model
- Victory
- Category
- Oilfield Drilling Equipment
- Condition
- USED
- Availability
- In stock
- Price or process
- Request price
- Quantity
- 1
- Lead time
- Not provided
- Location
- Houston, TX
- Fulfillment
- Pickup and shipping available
- Listed on
Key specifications
- Accommodation Capacity
- 140
- BOP Stack Rating
- 18-3/4" 15,000 psi 5-ram
- Derrick & Hoisting Compensator
- NOV DSMC â 1,000 kips, 25 ft stroke
- Derrick & Hoisting Derrick
- NOV 170 ft, 48 ft à 46 ft base
- Derrick & Hoisting Drawworks
- NOV 2040-UDBEL(L) â 4,000 HP
- Derrick & Hoisting Drill Line
- 2" drilling line
- Derrick & Hoisting Hook Load
- 1,000 ST static
- Derrick & Hoisting Top Drive
- NOV PS2-1000, 1,000 T
- Derrick Height
- 170ft
- Displacement
- 42570cc
- Draft (Drilling)
- 74.6ft
- Drawworks Power
- 4000HP
- Drilling Depth Capacity
- 35000ft
- Drilling Equipment Derrick
- NOV 170 ft, 1,000 ST hook load
- Drilling Equipment Drawworks
- NOV 2040-UDBEL(L), 4,000 HP
- Drilling Equipment Mud Pumps
- 4x NOV 14-P-220, 1,085 HP, 7,500 psi
- Drilling Equipment Rotary Table
- NOV T-6050, 60-1/2"
- Drilling Equipment Shale Shakers
- 4x Brandt AX-1, 1,500 gpm
- Drilling Equipment Top Drive
- NOV PS2-1000, 1,000 T
- General Accommodation
- 140 persons
- General Classification
- ABS +A1 Column Stabilised Drilling Unit
- General Design
- Odeco Victory
- General Displacement
- 42,570 MT
- General Draft (Drilling)
- 74.6 ft
- General Drilling Depth
- 35,000 ft
- General Main Deck
- 306 ft à 306 ft
- General Variable Deck Load
- 6,000 MT drilling
- General Water Depth
- 8,000 ft designed / 5,000 ft outfitted
- General Year Upgraded
- 2009
- Maximum Water Depth
- 8000ft
- Moonpool Dimensions
- 91 ft x 25 ft
- Mooring Winch Stall Tension
- 718kips
- Mud Pump Rating
- 1,085 HP, 7,500 psi
- Mud System Drill Water
- 13,169 bbl
- Mud System Fuel
- 6,234 bbl
- Mud System Liquid Mud
- 9,675 bbl storage
- Mud System Mud Pumps
- 4x NOV 14-P-220
- Mud System Pump Rating
- 1,085 HP, 7,500 psi each
- Mud System Shale Shakers
- 4x Brandt AX-1 Multisizers
- Power & Mooring Main Power
- 7x Himsen diesel, 6,120 kW each
- Power & Mooring Mooring
- 12-point Amclyde CTW 350/52 winches, 718-kip stall tension
- Power & Mooring Total Power
- 42,840 kW
- Power & Station Keeping Accommodation
- 140 persons
- Power & Station Keeping Deck Cranes
- 2x 90 MT Seatrax 9040 + 1x 65 MT
- Power & Station Keeping Main Power
- 7x Himsen diesel engines
- Power & Station Keeping Mooring
- 12-point, 8x Amclyde CTW 350/52 winches
- Power & Station Keeping Stall Tension
- 718 kips per winch
- Power & Station Keeping Total Power
- 42,840 kW
- Static Hook Load
- 1000lb
- Storage Bulk Cement
- 15,500 ft³
- Storage Drill Water
- 13,169 bbl
- Storage Fuel
- 6,234 bbl
- Storage Liquid Mud
- 9,675 bbl
- Storage Potable Water
- 2,904 bbl
- Subsea & BOP Annular Preventers
- 2x Hydril 18-3/4" 10,000 psi
- Subsea & BOP BOP Stack
- Hydril 18-3/4" 15,000 psi 5-ram
- Subsea & BOP Choke & Kill
- 8x 3-1/16" 15,000 psi
- Subsea & BOP Marine Riser
- Shaffer 21" FT-GB, 75 ft/joint
- Subsea & BOP Moonpool
- 91 ft à 25 ft
- Subsea & BOP Tensioners
- NOV 6-line, 2,400 kips total
- Subsea BOP Stack
- Hydril 18-3/4" 15,000 psi 5-ram
- Subsea Marine Riser
- Shaffer 21" FT-GB, 75 ft/joint
- Subsea Moonpool
- 91 ft à 25 ft
- Subsea Tensioners
- NOV 6-line, 2,400 kips total, 50 ft stroke
- Top Drive Capacity
- 1000tons
- Total Power Generation
- 42840kW
- Variable Deck Load
- 6000t
Supporting evidence
No supporting documents or certifications provided.
Description
A fifth-generation ultra-deepwater moored semisubmersible based on the Odeco Victory design, originally entered service in 1975 and comprehensively upgraded in 2009. Rated to 8,000 ft water depth and 35,000 ft drilling depth, the rig features a 170 ft NOV derrick with 1,000 ST hook load, four 1,085 HP NOV 14-P-220 mud pumps, a NOV PS2-1000 top drive, and 7x Himsen diesel power generation totalling 42,840 kW. A proven deep-water moored platform with a 12-point mooring system and 140-person accommodation.
